1. What is the use of this gauge?
B Check the diameter of cylindrical job
C Check the height and parallism of job
D Set the job on machines parallel to datum
2. What is the name of the file?
B Single cut file
C Double cut file
D Curved cut file
3. What is the name of the tool?
B Inside calliper
C Odd leg calliper
D Outside calliper
4. What is the cause for twisting defect in timber?
A Defective storage
B Uneven shrinkage
C Improper seasoning
D Irregularity in growth of branches
5. What is the use of mortise chisel?
A General chiselling work in wood
B Making rectangular holes in wood
C Paring and finishing joints in wood
D Light chiselling cleaning sharp corners and in wood
6. Which type of stake is used for sharp bends in sheet metal?
A Square stake
B Hatchet stake
C Blow horn stake
D Bevel edge square stake
7. Which type of cold chisel is used for squaring materials at the corners?
A Web chisel
B Cross cut chisel
C Half round chisel
D Diamond point chisel
8. Which type of calliper is used to draw parallel lines along the outer edges of the materials?
A Inside calliper
B Jenny calliper
C Outside calliper
D Spring joint calliper
9. What is the name of the drill bit?
B Taper shank bit
C Countersink bit
D Straight shank bit
10. What is the name of the stake used for general purpose in sheet metal work?
A Square stake
B Hatchet stake
C Blow horn square stake
D Bevel edge square stake
11. What is the number 1.25 indicates in ISO metric fine thread M12 x 1.25?
A Diametric of the thread
B Pitch of the thread
C Depth of the thread
D Length of the thread
12. What defect will occur in timber due to irregularity in growth of the branches?
A Knot
B Cupping
C Cracking
D Twisting
13. Which file is used for sharpening the blunt teeth of a tenon saw?
A Square file
B Round file
C Triangular file
D Half round file
14. Name the part marked ‘X’ of the file.
B Heel
C Tang
D Shoulder
15. What is the name of the tool?
B Inside calliper
C Outside calliper
D Firm joint calliper
16. What is the name of the angle marked ‘X’ of the chisel?
B Point angle
C Clearance angle
D Inclination angle
17. What is the use of firmer chisel?
A Paring and finishing joints
B General chiselling work
C Making rectangular holes in wood
D Light chiselling and to clean sharp corner
18. Which type of half lap joint is used if one part of a job meets another part at some distance from the ends?
A End-lap input
B Cross-lap joint
C Middle-lap joint
D Corner-half lap joint
19. Which type of notch is used for making a metal tray with 90° bend and an inside flange?
A ‘V’ notch
B Slant notch
C Square notch
D Straight notch
20. What is the purpose of hem folding in sheet metal work?
A Helps for forming a square box
B Helps for bending sheet metal easily
C Prevents burrs forming after cutting
D Prevents the sheet from damage
21. Which defect in the timber is caused to reduce its strength?
A Twisting
B Cupping
C Cracking
D Irregularity
22. What is the name of the hammer?
B Ball peen hammer
C Cross peen hammer
D Straight peen hammer
23. Which defect in timber is caused due to improper seasoning?
A Knot
B Twisting
C Cracking
D Cupping
24. What is the name of the formation of thread marked as X in the galvanized sheet pipe joint?
B Full form thread
C Tapered male thread
D Parallel female thread
25. Which type of notch is used for bending the edge of the sheet?
A ‘V’ notch
B Slant notch
C Square notch
D Straight notch
26. What is the purpose of cross cut cold chisel?
A Cutting keyways
B Cutting curved grooves
C Squaring materials at corners
D Removing metal from large flat surface
27. Which type of notch is used to make a job with 90° bend?
A ‘V’ notch
B Slant notch
C Square notch
D Straight notch
28. Which type of curve cutting hand saw is used for internal cutting in wood?
A Compass saw
B Key hole saw
C Coping saw
D Fret saw
29. What is the name of the stake used for sheet metal work?
B Hatchet stake
C Blow-horn stake
D Bevel-edge square stake
30. What is the name of tool?
B Tack hammer
C Cross pein hammer
D Straight pein hammer
31. Which type of chisel is used for separating metals after chain drilling?
A Flat chisel
B Web chisel
C Cross cut chisel
D Diamond point chisel
32. Which type of stake is used for riveting or seaming tapered cone shaped articles?
A Square stake
B Hatchet stake
C Blow horn stake
D Bevel edged square stake
33. Which causes knot defect in timbers?
A Defective storage
B Uneven shrinkage
C Growth of branches
D Improper seasoning
